Vbesty’s Sterilizer
- Commonly used sterilizers include steam sterilizers, spray sterilizers, and water bath sterilizers.
- We have over 10 years of production experience, with more than 90 cooperative customers.
- Our product features include: automatic operation controlled by an industrial computer, quick and easy switching between various sterilization processes, etc.
Applications of the sterilizer
Food industry
Pharmaceutical industry
Chemical industry
Beverage industry
- An autoclave, as a crucial piece of equipment, primarily serves to thoroughly sterilize and disinfect items using a high-temperature, high-pressure environment. This method effectively eliminates and greatly reduces the presence of various microorganisms, such as bacteria, viruses, and fungi, in items, thereby ensuring their safety and extending their shelf life.
- Owing to its exceptional performance in maintaining product hygiene, the autoclave is extensively employed across multiple sectors, including the food, chemical, beverage, and pharmaceutical industries. It has become vital equipment in these fields, enabling them to meet the stringent demands for product safety, quality, and prolonged shelf life.
Types of sterilizers
Steam sterilizer
- It utilizes the high-temperature lethality, penetrability, thermal conductivity of steam, as well as the principles of pressure and time control to efficiently and uniformly sterilize food, thereby ensuring food hygiene, safety, and shelf life.
- It has advantages such as fast heating speed, high thermal efficiency, uniform heating, and easy control of heating temperature. Steam is used as the heat source, which saves a large amount of water waste, and the condensate from steam can be recycled. It can not only be used for sterilization but also for food cooking, drying, and other processing procedures.
- Compared to other sterilization methods, steam sterilization has minimal destructive impact on food nutrition and taste, and can better maintain the original state of the food.
Spray sterilizer
- By evenly spraying high-temperature hot water onto the object’s surface, the core temperature of the item is effectively raised through heat conduction, resulting in thorough sterilization. Additionally, the steam produced by the evaporation of hot water further accelerates the temperature increase, enhancing the sterilization process. This method offers significant benefits, including low noise, minimal loss, rapid temperature adjustments, and no secondary pollution.
- The internal mechanism ensures uniform spraying in all directions, eliminating any blind spots for efficient sterilization. It is also water-efficient, reducing energy costs, and its highly automated design enhances ease of operation and production efficiency. It is well-suited for sterilizing a variety of materials, including plastic items, soft packaging, and vacuum-sealed products.
- The improved heating and cooling speeds significantly reduce the sterilization time. With low resource and energy consumption, this method achieves efficient and energy-saving sterilization.
Water bath sterilizer
-
The equipment utilizes high-temperature water as the sterilization medium. By fully immersing items in hot water, it creates a high-temperature and high-pressure environment, effectively killing various microorganisms and significantly extending the product’s shelf life.
-
Its unique design ensures that items are exposed to sterilizing water 360° without any dead angles, leveraging water’s high heat transfer efficiency to achieve uniform and thorough sterilization.
-
The sterilization water can be recycled, greatly reducing resource waste and enhancing economic efficiency. This technology is particularly suitable for sterilizing irregularly shaped, large objects, and products in glass packaging.
Product features
Custom Sizing
Customize suitable sizes based on customer’s specific needs, factory area, and detailed cargo volume information.
Security Assurance
The sterilization pot door employs a unique cylinder, photoelectric switch, and mechanical interlock for triple safety assurance during use.
Electrical Protection
The control system and circuits are waterproofed to IP65, preventing malfunctions and damage from water exposure.
Automatic Control
The PLC program controls sterilization, with alarms for temp and pressure issues, and stores protocols for easy product changes.
%
